4" x 2" Ductile Steel Wheel Kingpinless Rigid Caster - 1,500 Lbs Capacity

SKU

P50042DUCT
$40.36

4" x 2" Ductile Steel Wheel Kingpinless Rigid Caster - Part #: P50042DUCT

Ductile steel wheels are the next level up in capacity & durability from cast iron wheels. Made from a combination of alloys that provide excellent tensile strength, these wheels come with extra thick treads, hubs & walls. While ductile steel is very resilient, it is tough on floors & could lead to floor damage.

For heavy duty floor protective wheels, be sure to check out our polyurethane wheels. For maximum capacity & durability, check out our premium forged steel wheel casters.

* Please note temperature ratings are dependent upon the bearing selected. Unless noted otherwise in the options, bearings will have a 180°F temperature rating.

Specifications:

Load Capacity (lbs.): 1,500 Link to Matching Swivel Caster:  P5104201201
Wheel Diameter: 4" Caster Rig Material Type: AISI 1045 Steel
Tread Width: 2" Caster Rig Color/Finish: Zinc Plated
Wheel Type: Ductile Steel Swivel or Rigid Caster: Rigid
Wheel Bearing Type: See Bearings Options Swivel Radius: N/A
Overall Height: 5-5/8" Swivel Construction: N/A
Temp Range:  -45°F to 800°F Mounting Plate: 4" x 4-1/2"
Wheel Hardness: Rockwell 75B  Bolt Hole Pattern: 2-5/8" x 3-5/8" slotted to 3" x 3"
Wheel Color: Red Mounting Bolt Size: 3/8" or Smaller
Link to Replacement Wheel: LDS420 Weight: 7.12 lbs.
