4" x 2" Forged Steel V-Groove Wheel Kingpinless Swivel Brake Caster - 2000 Lbs Capacity SIDE VIEW
4" x 2" Forged Steel V-Groove Wheel Kingpinless Swivel Brake Caster - 2000 Lbs Capacity SIDE VIEW

4" x 2" Forged Steel V-Groove Wheel Kingpinless Swivel Brake Caster

SKU

P5104200VG2TLB
$122.49

4" x 2" Forged Steel V-Groove Wheel Kingpinless Swivel Brake Caster - Part # P5104200VG2TLB

V groove wheels are designed to guide equipment by rolling on inverted angle iron track, however, they can also operate off the track thanks to the tread on either side of the v-groove.

Solid steel wheel casters are the premium of all the steel wheel casters. It offers the maximum weight capacity, impact strength, and durability of all caster wheels. For a metal wheel with similar capacities and durability, but is more economical, check out our ductile steel wheel casters.

* Our kingpinless swivel caster rigs outlast traditional kingpin designs by preventing stretch-induced plate & fork separation. Providing more durability & more capacity (depending on the wheel) while reducing downtime and replacements."

Specifications:

Load Capacity (lbs.):  2000 lbs. Link to Matching Rigid Caster: P5004200VG2TLB
Wheel Diameter: 4" Caster Rig Material Type:  Rockwell 80B
Tread Width: 1-3/4" Caster Rig Color/Finish: Chrome
Wheel Type: Solid Steel V-Groove Swivel or Rigid Caster: Swivel
Wheel Bearing Type: Ball Bearing Swivel Radius: 3-3/16"
Overall Height: 5-5/8" Swivel Construction: Kingpinless - Heat Treated Precision Machined Raceway
Temp Range: -45°F to 600°F  Mounting Plate: 4" x 4-1/2"
Wheel Durometer: Rockwell 80B Bolt Hole Pattern: 2-5/8" x 3-5/8" slotted to 3"x 3"
Wheel Color: Silver Mounting Bolt Size: 3/8" or Smaller
Link to Replacement Wheel: PAH108 Weight: 8.89 lbs.
