6" x 2" Forged Steel Wheel Kingpinless Rigid Caster - 2,000 Lbs Capacity Heavy Duty
6" x 2" Forged Steel Wheel Kingpinless Rigid Caster - 2,000 Lbs Capacity Heavy Duty

6" x 2" Forged Steel Wheel Kingpinless Rigid Caster

SKU

P5006201252
$134.41

6" x 2" Forged Steel Wheel Kingpinless Rigid Caster - Part # P5006201252

Forged steel wheel casters are the premium of all the steel wheel casters. The forged steel wheel is made from ASTM 1045 high carbon steel that is hot drop forged. It offers the maximum weight capacity, impact strength & durability of all caster wheels. While forged steel is incredibly resilient, it is the harshest wheel type for floors & could lead to floor damage.

For heavy duty floor protective wheels, be sure to check out our polyurethane on iron wheels. For a metal wheel with similar capacities and durability, but is more economical, check out our ductile steel wheel casters.

* Please note temperature ratings are dependent upon the bearing selected. Unless noted otherwise in the options, bearings will have a 180°F temperature rating.

Specifications:

Load Capacity (lbs.): 2,000 Link to Matching Swivel Caster: P5106201251
Wheel Diameter: 6" Caster Rig Material Type: Cold Rolled Steel
Tread Width: 2" Caster Rig Color/Finish: Bright Zinc Plated
Wheel Type: Forged Steel Swivel or Rigid Caster: Rigid
Wheel Bearing Type: See Bearings Options Swivel Radius: N/A
Overall Height: 7-1/2" Swivel Construction: N/A
Temp Range:  -45°F to 1,300°F Mounting Plate: 4" x 4-1/2"
Wheel Hardness: Rockwell 80B Bolt Hole Pattern: 2-5/8" x 3-5/8" slotted to 3" x 3"
Wheel Color: Silver Mounting Bolt Size: 3/8" or Smaller
Link to Replacement Wheel: LFS60JS84 Weight: 12.112 lbs.
