6" x 2-1/2" Ductile Steel V-Groove Wheel (Wide Hub) - 3,500 Lbs Capacity

6" x 2-1/2" Ductile Steel V-Groove Wheel (Wide Hub) - Part # LDVG625

V-Groove wheels are designed to guide equipment along inverted angle iron tracks but can also function without a track due to the tread on both sides of the V-groove. Made from a combination of alloys that provide excellent tensile strength, these wheels come with extra thick treads, hubs & walls. Ductile steel is a step up from cast iron, offering higher capacity & temperatures. For even greater capacity, consider the heavier-duty forged steel wheels.

*Please note temperature ratings are dependent upon the bearing selected. Unless noted otherwise in the options, bearings will have a 180°F temperature rating.

Specifications:

Capacity: 3,500 Lbs.	Wheel Type:Ductile Steel V-Groove
Wheel Diameter:6"	Hub Length (without Bearings):3-1/4"
Tread Width:2-1/2"	Hub Length (with Bearings):See Bearing Options
Groove Width:7/8"	Groove Depth: 7/16"
Bearing Type:None	Wheel Durometer:Rockwell 74B
Plain Bore ID:1-15/16"	Wheel Tread Shape:V-Groove
Accepted Axle/Bearing ID:See Bearing Options	Wheel Color:Red
Temp Range: -45˚F to 800˚F	Weight:9.646 lbs

Capacity:3,500 lbs.

Wheel Type:Ductile Steel V-Groove

Wheel Diameter:6"

Tread Width:2-1/2"

Hub Length (without Bearings): 3-1/4"

Hub Length (with Bearings): See Bearing Options

Groove Width: 7/8"

Groove Depth: 7/16"

Bearing Type:None

Plain Bore ID:1-15/16"

Accepted Axle/Bearing ID:See Bearing Options

Wheel Durometer:Rockwell 74B

Wheel Tread Shape:V-Groove

Temp Range: -45˚F to 800˚F

Wheel Color:Red

Weight: 9.646 lbs
